The switching, protection and distribution layer of your substation — MV line-ups, ring main units for distribution networks, and the LV boards and ATS panels that feed the final loads.
Air-insulated metal-clad and metal-enclosed switchgear with vacuum circuit breakers, protection relays, CTs / VTs and metering — line-ups built panel by panel from your SLD, for incomer, feeder, bus-coupler and transformer protection duties.
Compact RMUs for ring and radial distribution networks: SF6-insulated or solid-insulated, in common 2-way, 3-way and 4-way functional combinations, extensible types available. Cable boxes and fault indicators per project requirement.
Main and sub distribution boards, automatic transfer switch (ATS) panels, capacitor compensation banks and control panels — form and rating per project specification, wired and tested before dispatch.
| MV rated voltage | 12 / 17.5 / 24 / 36 / 40.5 kV classes (typical) |
|---|---|
| MV rated current | 630 A / 1,250 A busbar ratings typical; feeder ratings per SLD |
| Breaking devices | Vacuum circuit breakers, load-break switches and switch-fuse combinations |
| RMU insulation | SF6 gas-insulated or solid-insulated, sealed for life designs |
| Protection | Numerical or electronic protection relays, settings per project protection study |
| LV boards | 400 / 415 V, form 1 to form 4 construction, ATS and capacitor banks on request |
| Standards | MV assemblies to IEC 62271 series; LV assemblies to IEC 61439 |
| Testing | Routine tests per panel, wiring and functional checks, test reports with the delivery documents |
Typical ranges for orientation only. Panel schedules are always built from the project SLD — send the drawing and we return a panel-by-panel proposal.
Switchgear is quoted from drawings, not from guesses. Send your single-line diagram and we come back with the panel schedule, breaker and relay selection, and any conflicts with the transformer and LV side flagged in the gap review.
Send Your SLD on WhatsApp
